PUSH-LITE SWITCHES AND INDICATORS
PHONE: 773 792-2700
278
SWITCHES
?
* Please visit the product pages on our website for the most up-to-date product information
PUSH-LITE ? SWITCHES AND INDICATORS (continued)
U.L. LISTED, MOMENTARY & PUSH-LOCK/PUSH-RELEASE
Part
Housing/
AC Ratings (max.)
Number
Pushbutton
Action 1
Switching
non-inductive
Contacts
Circuit
Listing
Terminals
SINGLE LAMP
? 26U1003
M
SPDT
8 A, 125 V
1-C
UL
? 26U1004
? 26U1007
Black/White
M
PL/PR
DPDT
SPDT
8 A, 125V
8 A, 125V
Silver
2-C
1-C
UL
UL
Solder Lug
? 26U1008
PL/PR
DPDT
8 A, 125 V
2-C
UL
TWIN LAMP
? 26U1005
M
SPDT
8 A, 125 V
1-C
UL
? 26U1006
? 26U1009
Black/White
M
PL/PR
DPDT
SPDT
8 A, 125V
8 A, 125V
Silver
2-C
1-C
UL
UL
Solder Lug
? 26U1010
PL/PR
DPDT
8 A, 125 V
2-C
UL
? Special order only; contact Switchcraft for price and delivery. NOTE: 1 M = Momentary; PL/PR = Push-Lock/Push-Release
SERIES PL9000 - PL ? INDICATORS
Create unlimited combinations of rows and/or matrix arrays
with or without Push-Lite switches. A perfect match for front
panel appearance Push-Lite switches - but functions only as
a lighted indicator. Mounts same as Push-Lite switches:
behind panel depth 1.341" (35.55mm) maximum uses
same lamp, color filter, snap inserts, light divider and
optional mounting barriers as Push-Lite ? switches.
Part Number
PL9105
? PL9205
Description
Black housing;
uses 1 or 2 lamps.
White screen.
Same as PL-9105
except gray housing.
PUSHBUTTON/INDICATOR SCREENS
Series PL500 Pushbuttons/Indicator Screens are available
separately for use with Push-Lite switches or PL Indicators for
in-the-field substitution and/or replacement.
COLOR FILTER SNAP-INSERTS
Translucent plastic filters for special color coding in Push-Lite
switch and PL Indicators. Use with white or clear pushbuttons.
Part Number
Color
Part Number
Color
SERIES PL300 - Full Display Color Filters
PL501
PL503
PL504
PL505
Red
Green
Blue
White
PL508
PL512
PL513
Yellow
Clear
Amber
Part Number
PL303
PL305
PL308
Color
Green
White
Yellow
OPTIONAL MOUNTING BARRIERS
Molded plastic barriers separate Push-Lite switches, PL
Indicators, or combinations of Push-Lite switches and PL
Indicators and prevent accidental operation of adjacent
switches. Series PL100: end barrier. Series PL200: center
barrier. Two required between adjacently mounted switches.
Push-Lite switch is shown with two PL102 end barriers
installed.
LIGHT DIVIDER
Light divider for Push-Lite switch pushbuttons and PL Indicator
screens; separates lighting from twin lamps. Order light divider for
each switch or indicator specified where split-face lighting is
desired. Order PL551.
BASIC SCHEMATIC
Switch circuitry can be described as combinations of basic schematic circuits
as shown below. N.O. means normally open; N.C. means normally closed.
Part Number
PL102
? PL111
PL202
? PL211
Description
End barrier, black
End barrier, gray
Center barrier, black
Center barrier, gray
? Special order only; contact Switchcraft for price and delivery.
The above are strictly electrical schematics and do not necessarily indicate
relative solder lug positions.
DIMENSIONS ARE FOR REFERENCE ONLY
www.switchcraft.com
Inch
(mm)
? Registered trademark of Switchcraft, Inc.
Note: Contact your Switchcraft Representative for price and delivery
